PK 18502 SH High Performance

High variety of uses maximizes profitability throughout a crane's entire lifetime

	Lifting moment	Outreach	Slewing angle	Slewing torque	Pressure	Pump capacity	Crane weight	Crane height	Crane width	Installation width	Max stroke length	Max. lifting capacity	Load vertical
A	17.0 mt	8.1 m	420 °	2.0 mt	36.5 Mpa	60-80 l/min	1890 kg	2270 mm	2510 mm	830 mm	7947.72 mm	6100 kg	2150 kg
B	16.7 mt	10.3 m	420 °	2.0 mt	36.5 Mpa	60-80 l/min	2030 kg	2270 mm	2510 mm	830 mm	10177.72 mm	6000 kg	1560 kg
C	16.3 mt	12.6 m	420 °	2.0 mt	36.5 Mpa	60-80 l/min	2150 kg	2270 mm	2510 mm	900 mm	12407.72 mm	5850 kg	1180 kg
D	16.0 mt	14.8 m	420 °	2.0 mt	36.5 Mpa	60-80 l/min	2260 kg	2270 mm	2510 mm	940 mm	14637.72 mm	5750 kg	900 kg
E	15.7 mt	17.0 m	420 °	2.0 mt	36.5 Mpa	60-80 l/min	2370 kg	2270 mm	2550 mm	940 mm	16867.72 mm	5650 kg	690 kg
